DuraLabel Toro specifications are subject to change without notice.
Printer
- Type: Thermal Transfer
- Print Speed: up to 3" per second
- Resolution: 300 dots per inch
- Print Width: 4.0"
- Print Length: 30" using Label Writer software
- Unlimited length using DuraSuite software and EXT cut setting
Indicators & Buttons
- Indicators: Power, Printer Status, Supply Status, Battery Status
- Buttons: Power, Supply Feed, Keyboard Release, Screen Release, Battery Release
Communication and Data Storage
- Communications: USB 2.0 (2x USB-A, 1x USB-B), Wi-Fi USB adapter, Optional Ethernet port
- Data Storage: 4GB Flash (long-term), 1GB SDRAM (short-term)
Power Requirements
- Input Voltage: 24 VDC, 5A
- Different AC adapters available for worldwide usage
Capabilities
- Create, edit, save, and print label designs with internal software
- Open and print designs created with common software (including support for .DOC/.DOCX and .PDF formats)
- Lock system with user passwords
- No user software may be installed
Environment
- Operating Temperature: 41?F ? 104?F (5?C ? 40?C)
- Operation Humidity: 30% ? 85%, non-condensing
- Storage Temperature: -4?F ? 122?F (-20?C ? 50?C)
- Storage Humidity: 10% ? 90%, non-condensing
- Ventilation: Fan mounted on circuit board
Label Stock
- Type: Continuous, Black Mark & Die-Cut
- Width: 0.20" minimum, 4" maximum
Ribbon Supply
- Premium Resin
- Width: 4.17 inch (106 mm)
- Capacity: 360' with 0.5" core diameter
Printer Body
- Dimensions: 13.5"W x 10.25"D x 8.5"H
- 8 lbs (6.26 kg), excluding supplies
